Yamaha YZF-R7 - Disassembling the Rear Wheel

7 - 11
CHAS
REAR WHEEL, BRAKE DISC, AND REAR WHEEL
SPROCKET
Order Job/Part Q’ty Remarks
Disassembling the rear wheel Remove the parts in the order listed.
1 Spacer 1
2 Bearing 1
3 Spacer 1
4 Oil seal 1
5 Circlip 1
6 Bearing 1
For assembly, reverse the disassembly
procedure.
