Conformance to UL Standard
10- 11
10
Conformance to UL Standard
To comply with UL standard, follow the appropriate installation instructions.
Installation Site
Install the Inverter in a pollution degree 2 environment or equivalent.
Ambient Temperature
Enclosed wall-mounted type (IP20/UL Type 1): -10 to +40°C
Open chassis type (IP00): -10 to +45°C
Main Circuit Terminal
The closed-loop connectors and the insulation caps must be installed on conductors before installing to termi-
nal blocks.
Use UL Listed closed-loop connectors and insulation caps shown below.
Use rated 75°C copper wire.
Yaskawa recommends UL-Listed crimp terminals made by JST and UL Recognized insulation cap by Tokyo
DIP.
Table 10.2 Inverter, JST Crimp Terminal, and Tokyo DIP Insulation Cap Models
Inverter
Model
CIMR-
G7A
Input
Wire Size
Input JST Kit P/N
Tokyo DIP
Insulation
Cap
Model
Output
Wire Size
Output JST Kit P/N
Tokyo DIP
Insulation
Cap
Model
2015 2 AWG R38-8 TP-038 4 AWG R22-8 TP-022
2018 2 AWG R38-8 TP-038 2 AWG R38-8 TP-038
2022 1/0 AWG R60-8 TP-060 1/0 AWG R60-8 TP-060
2030 3/0 AWG 80-10 TP-080 3/0 AWG 80-10 TP-080
2037 4/0 AWG R100-10 TP-100 4/0 AWG R100-10 TP-100
2045 1/0 AWG R60-10 (2 per phase) TP-060 1/0 AWG R60-10 (2 per phase) TP-060
2055 3/0 AWG 80-10 (2 per phase) TP-080 3/0 AWG 80-10 (2 per phase) TP-080
2075 250 kcmil R150-12 (2 per phase) TP-150 4/0 AWG R100-12 (2 per phase) TP-100
2090 400 kcmil R200-12 (2 per phase) TP-200 250 kcmil R150-12 (2 per phase) TP-150
2110 400 kcmil R200-12 (2 per phase) TP-200 300 kcmil R150-12 (2 per phase) TP-150
4018 6 AWG R14-6 TP-014 6 AWG R14-6 TP-014
4022 4 AWG R22-6 TP-022 4 AWG R22-6 TP-022
4030 2 AWG R38-8 TP-038 4 AWG R22-8 TP-022
4037 2 AWG R38-8 TP-038 2 AWG R38-8 TP-038
4045 1/0 AWG R60-8 TP-060 1/0 AWG R60-8 TP-060
4055 3/0 AWG 80-10 TP-080 3/0 AWG 80-10 TP-080
4075 4/0 AWG R100-10 TP-100 4/0 AWG R100-10 TP-100
4090 1/0 AWG R60-10 (2 per phase) TP-060 1/0 AWG R60-10 (2 per phase) TP-060
4110 3/0 AWG 80-10 (2 per phase) TP-080 3/0 AWG 80-10 (2 per phase) TP-080
4132 3/0 AWG 80-12 (2 per phase) TP-080 3/0 AWG 80-12 (2 per phase) TP-080
