Yealink VC800 Administrator's Guide

VC800 Video Conferencing System Introduction
3
- 1 x Yealink extension port (RJ-45) connect to VCH50/CP960 Phone
- 1 x 10/100/1000M Ethernet port
- 2 x USB 2.0
- 1 x Power port
- 1 x Security lock slot
- 1 x Reset slot
VCH50 Connections
- 1 x RJ45 port connects to VC800 codec
- 1 x RJ45 port connects to CP960
- 1 x HDMI input for content sharing (with audio)
- 1 x Mini-DP input for content sharing (with audio)
- 1x USB 2.0 for recording
Full-HD PTZ Camera
- 1920 x 1080 video resolution
- 60 frame rate
- 12x optical zoom PTZ camera
- Horizontal field of view: 70°
- Vertical field of view: 42°
- Pan angel range: +/- 100°
- Tilt angel range: +/- 30°
- Beauty shot
Icon Instructions
Icons on Display Device
Icons appearing on the display device are described in the following table:
Icons
Descriptions
Network is available
CP960 conference phone is not connected

Yealink VC800 Specifications

General

Brand	Yealink
Model	VC800
Category	Conference System
Language	English
