Yealink VC800 Administrator's Guide

Administrator’s Guide for Yealink VC800 Video Conferencing System
16
You can fasten all cables with cable ties after all devices are connected.
Installing the VC800 Video Conferencing System
You can choose to mount the VC800 codec on your TV or a wall, depending on your actual
needs.
Mounting the VC800 Codec on a TV
When the thickness of your TV is between 35-120 mm, you can mount the VC800 codec on your
TV.
Do the following:
1. Open the baffle.
2. Push the bracket along the track.
3. Remove the protection of the Velcro.
4. Put the L-bracket on the top of the TV.
5. Make sure the back of the TV is clean, and then adjust the bracket to ensure close
adhesion to the back of the TV with Velcro.
6. Lock the VC800 codec to the L-bracket with the M3×8 screws.

Yealink VC800 Specifications

General

Brand	Yealink
Model	VC800
Category	Conference System
Language	English
