ENGINE
6 - 5
ATLANTIC 125 - 200
6.1.3. ENGINE COMPONENTS THAT CAN BE
REMOVED LEAVING THE ENGINE IN THE
FRAME
The components listed below can be removed and refitted
with no need to take the engine out of the frame.
LEFT SIDE OF ENGINE
• Transmission casing cover
• Automatic converter
• Clutch assembly
• Drive belt
RIGHT SIDE OF ENGINE
• Spark plug
• Flywheel
• Ignition casing
• Stator coil
• Pick-up
• Coolant pump
• Secondary air system
TOP END OF ENGINE
• Carburetor
• Intake manifold hose
• Starter motor
• Coolant thermistor
• Thermal expansion valve
• Timing chain tensioner
FRONT END OF ENGINE
• Valve tappet cover
• Camshaft
• Cylinder head
• Cylinder
• Piston
BOTTOM END OF ENGINE
• Exhaust silencer
• Engine oil filter

APRILIA ATLANTIC 500 sprint Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Transmission	Automatic
Rear Suspension	Dual shock absorbers
Front Brake	Single disc
