CHASSIS
7 - 71
ATLANTIC 125 - 200
7.8.4. DRAINING THE FRONT FORK
NOTE Make sure to have a container having a capacity
greater than,
1.7.1., ready at hand before proceeding.
• Place the slider in a vice with soft (aluminium) jaws.
WARNING
The stanchion-and-slider assembly contains
oil. Do not turn it over or tilt it during removal.
• Remove the top cap.
• Push down the damping cylinder just enough to give
access to the retaining ring (1).
• Remove the retaining ring (1).
• Remove the cap complete with O-ring.

APRILIA ATLANTIC 500 sprint Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Transmission	Automatic
Rear Suspension	Dual shock absorbers
Front Brake	Single disc
