CHASSIS
7 - 61
ATLANTIC 125 - 200
7.6.6. REAR BRAKE DISC INSPECTION
NOTE These procedures must be performed with the brake
disc installed to the wheel.
• Check for wear measuring disc thickness with a
micrometer gauge at different positions around the
disc.
NOTE When a disc is worn beyond the service limit even at
just one position, the disc must be replaced, see
7.7.7.
Disc thickness limit: 4.5 mm.
• Check for disc run-out using a dial gauge. Replace disc
when the maximum run-out measured exceeds the
disc run-out limit, see
7.7.7.
Disc run-out limit: 0.3 mm.

APRILIA ATLANTIC 500 sprint Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Transmission	Automatic
Rear Suspension	Dual shock absorbers
Front Brake	Single disc
