CHASSIS
7 - 35
ATLANTIC 125 - 200
7.1.27. REMOVING THE TAIL LIGHT UNIT
• Remove the tail,
7.1.5.
RIGHT
• Disconnect the connector (1).
• Extract the tail light bulb (2).
• Release and remove the three screws (3).
• Remove the right light unit.
LEFT
• Disconnect the connector (1).
• Release and remove the three screws (4).
• Remove the left light unit.
