CHASSIS
7 - 44
ATLANTIC 125 - 200
7.3.4. CENTRE STAND REMOVAL
TORQUE WRENCH SETTINGS
Nut (1) 27 Nm (2.7 kgm)
• Place the vehicle on the side stand.
• Unhook the two springs.
• Release and remove the nut (1).
• Withdraw the bolt from the opposite end.
• Remove the centre stand.
WARNING
Grease the sliding areas on refitting and avoid
damage to the seals. Tighten the nut and make
sure the stand folds up smoothly in the correct
position.

APRILIA ATLANTIC 500 sprint Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Transmission	Automatic
Rear Suspension	Dual shock absorbers
Front Brake	Single disc
