APRILIA ATLANTIC 500 sprint User Manual

CHASSIS
7 - 22
ATLANTIC 125 - 200
7.1.16. HELMET COMPARTMENT REMOVAL
• Remove the tail,
7.1.5.
• Remove the saddle,
7.1.2.
• Remove the battery and extract the main fuse carrier,
7.2.1.
• Release and remove the two screws (1) at the front
end.
• Release and remove the two screws (2) at the rear
end.
• Lift the helmet compartment.
• Release and remove the two retaining screws (3) of
the expansion reservoir.
• Shift the expansion reservoir, but leave it connected
to the coolant hoses.
• Disconnect the two power socket connectors (4).
• Remove the helmet compartment.

APRILIA ATLANTIC 500 sprint Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Transmission	Automatic
Rear Suspension	Dual shock absorbers
Front Brake	Single disc
