CHASSIS
7 - 52
ATLANTIC 125 - 200
7.4.5. REFITTING THE FRONT WHEEL
TORQUE WRENCH SETTINGS
Pinch bolt (1) 12 Nm (1.2 kgm)
Wheel spindle 40 Nm (4.0 kgm)
Screws (2) 25 Nm (2.5 kgm)
• Position the wheel between the fork legs.
• Locate the speedometer drive to the wheel.
• Smear a light coat of grease over the total length of the
wheel spindle, see
1.8.1.
• Tighten the wheel spindle from the right side.
• Tighten the pinch bolt (1).
• Position the brake calliper to the brake disc.
• Tighten the two screws (2).

APRILIA ATLANTIC 500 sprint Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Transmission	Automatic
Rear Suspension	Dual shock absorbers
Front Brake	Single disc
