GENERAL INFORMATION
1 - 15
ATLANTIC 125 - 200
1.7. TECHNICAL DATA
1.7.1. TECHNICAL DATA
DIMENSIONS
Max. length 2100 mm
Max. width (rear-view mirrors included) 900 mm
Seat height 790 mm
Max. height (front part of the fairing included) 1400 mm
Min. ground clearance 190 mm
Unladen weight (in the direction of travel) 160 kg
Wheel base 1470 mm
ENGINE
Make Piaggio Leader 125 4T 4V water-cooled
Make (200) Piaggio Leader 200 4T 4V water-cooled
Type
Single-cylinder, four-stroke with four valves, wet forced
lubrication, overhead camshaft.
Number of cylinders 1
Total displacement 124 cu. cm
Total displacement (200) 197.75 cu. cm
Bore/stroke 57 mm /48.6 mm
Bore/stroke (200) 72 mm /48.6 mm
Intake valve clearance 0.10
Exhaust valve clearance 0.15
Compression ratio 12.5 ± 0.5: 1
Compression ratio (200) 11.5 ± 0.5: 1
Starting Electric
Engine idling rpm 1750 ± 100 rpm
Clutch Centrifugal type
Gearbox Automatic
Cooling system
Liquid-type (50% water + 50% coolant), with forced
circulation
CAPACITY
Fuel (with reserve) 10.5 liters
Fuel reserve 1.5 liters
Engine oil
- changing engine oil only 1000 cu. cm
- changing engine oil and engine oil filter 1100 cu. cm
- changing for engine overhaul 1150 cu. cm
Transmission oil 250 cu. cm
Coolant 1.2 liters
Seats 2
Vehicle max. load (rider + passenger + luggage) 210 kg
TRANSMISSION
Variator Continuous automatic
Primary With V-belt
Secondary Gear-type
Engine/wheel total ratio (125)
- short 1:28.03
- long 1:8.41
Total wheel/engine ratio (200)
- short 1:21.05
- long 1:7.37
CARBURETOR
Model (125) WVF 7C* ø29 WALBRO
Model (200) CVK 7C* 30 KEIHIN
Model (200) WVF 7D* ø29 WALBRO
FUEL SUPPLY
Type Vacuum pump
Fuel Premium-grade petrol, min. O.N. 95 (N.O.R.M.) and 85
(N.O.M.M.)
FRAME
Type Single-beam with twin overlapped cradle
Steering inclination angle 27°
Trail 104 mm
