CHASSIS
7 - 30
ATLANTIC 125 - 200
7.1.23. REMOVING THE LEFT SWITCH
• Release and remove the three screws (1) at the lower
end.
• Release and remove the screw (2).
• Remove the switch lower cover.
• Disconnect the light connector (3).
• Disconnect the direction indicator connector (4).
• Disconnect the horn connector (5).
• Remove the switch upper cover.
