APRILIA ATLANTIC 500 sprint User Manual

ROUTINE MAINTENANCE
2 - 11
ATLANTIC 125 - 200
2.4.3. CHECKING THE BATTERY ELECTROLYTE
LEVEL
Carefully read
2.4.1.
To check battery electrolyte level, proceed as follows:
• Raise the vehicle on center stand.
• Raise the seat.
• Undo and remove the two screws (1).
• Remove battery protection.
• Make sure that the fluid level is included between the
“MIN” and “MAX” marks, etched on the battery side.
If this is not the case:
• Remove the battery, see
7.2.1.
• Remove battery plugs.
WARNING
Top up the electrolyte using distilled water
only. Do not fill above the “MAX” mark as the
level increases during recharging.
• Top up with distilled water.

APRILIA ATLANTIC 500 sprint Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Transmission	Automatic
Rear Suspension	Dual shock absorbers
Front Brake	Single disc
