CHASSIS
7 - 76
ATLANTIC 125 - 200
7.8.7. REFITTING THE STANCHION TUBES AND
SLIDERS
• Place the slider in a vice with soft (aluminium) jaws.
• Position the shim (1).
WARNING
Make sure no dirt or objects fall into the slider
or the stanchion.
NOTE Apply a light film of fork oil to the seals and bushes
before assembly.
• Insert the washer.
• Insert the oil seal.
• Insert the retaining ring.

APRILIA ATLANTIC 500 sprint Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Transmission	Automatic
Rear Suspension	Dual shock absorbers
Front Brake	Single disc
