CHASSIS
7 - 25
ATLANTIC 125 - 200
7.1.18. SPLASHGUARD REMOVAL
• Remove the complete headstock,
7.8.1.
• Remove the central tunnel,
7.1.7.
• Shear the tie (1) on both sides.
• Withdraw both air scoops from the radiator.
• Release and remove the four screws (2) at both sides.
• Release and remove the centre screw (3).
• Remove the splashguard.

APRILIA ATLANTIC 500 sprint Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Transmission	Automatic
Rear Suspension	Dual shock absorbers
Front Brake	Single disc
