CHASSIS
7 - 40
ATLANTIC 125 - 200
7.3.2. REMOVING THE DASHBOARD/WINDSHIELD
MOUNTING BRACKET
TORQUE WRENCH SETTINGS
Screws (2) 12 Nm (1.2 kgm)
Screws (5) 10 Nm (1.0 kgm)
• Remove the headlight,
7.2.7.
• Remove the dashboard,
7.2.6.
• Release all ties fitted to the dashboard/windshield
mounting bracket.
• Disconnect the right switch connector.
• Disconnect the left switch connector.
• Disconnect the ignition switch connector (1).
• Take the auxiliary fuse carrier out of its mount.

APRILIA ATLANTIC 500 sprint Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Transmission	Automatic
Rear Suspension	Dual shock absorbers
Front Brake	Single disc
