CHASSIS
7 - 36
ATLANTIC 125 - 200
7.1.28. COIL REMOVAL
Remove the air dam,
7.1.8.
Disconnect the spark plug cap.
Disconnect the two coil connectors (1).
Release and remove the bolt (2) and collect the nut.
