CHASSIS
7 - 48
ATLANTIC 125 - 200
7.4.2. FRONT WHEEL REMOVAL
TORQUE WRENCH SETTINGS
Pinch bolt (1) 12 Nm (1.2 kgm)
Wheel spindle 40 Nm (4.0 kgm)
WARNING
Use great care when removing and refitting the
wheel to avoid damaging the brake hoses,
brake discs and brake pads.
• Place the vehicle on the centre stand.
• Place a support underneath the frame.
• Remove the brake calliper,
7.7.2.
• Slacken the pinch bolt (1).
• Release and remove the wheel spindle.
• Collect the speedometer drive.
• Remove the wheel.
WARNING
Do not operate the brake lever with the wheel
removed, or the brake calliper piston might fall
out leading to loss of brake fluid.

APRILIA ATLANTIC 500 sprint Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	460 cc
Cooling System	Liquid-cooled
Fuel System	Electronic fuel injection
Front Suspension	Telescopic fork
Transmission	Automatic
Rear Suspension	Dual shock absorbers
Front Brake	Single disc
