Handling rolls
Setting the Roll on the Roll Holder
Note
• Printed rolls will not work correctly . Cut away the printed portion before loading the roll.
• For details on supported sizes and types of rolls, see Paper Sizes (→P .173) or the Paper Reference
Guide . ( → P .167)
• Cut the edge of the roll paper if it is uneven, dirty , or has tape residue.
Uneven, dirty , or sticky edges may cause feeding problems and af fect the printing quality .
Be careful not to cut through any barcodes printed on the roll.
• Wind up the roll so that the edge is even across the roll.
• After pressing the Load/Eject button, you can refer to instructions on the Display Screen as you load
the paper .
1. Lift the Holder Stopper lever (a) from the shaft side to unlock it. Holding the Holder Stopper at
the position indicated (b), remove it from the Roll Holder .
Handling Paper 177
To Next Page
