Adjusting the feed amount
Adjusting the Measurement Scale for Better Accuracy
Use Adjust Length to ensure that lines in CAD drawings are printed at exactly the right length.
T wo Adjust Length options are available ( A: Standard and B: Other ), and the settings for both options
are saved.
The setting of B: Other is applied when printing in high-speed mode from software or systems other than
the printer driver . In other cases, the A: Standard setting is applied.
Check the Feed Priority setting before using Adjust Length . ( → P .577)
Note
• Use paper of the same type and size for adjustment as you will use for printing.
• If you have selected Easy Settings on the printer , follow these steps to conrm the Print Quality setting.
• Windows: Click V iew Settings on the Main tab to display the V iew Settings dialog box.
• Mac OS X: Click V iew set. on the Main pane to display the V iew settings dialog box.
Paper to Prepare
Rolls An unused roll at least 10 inches wide
Sheets One sheet of unused paper of at least A4/Letter size
Follow these steps to change the Adjust Length setting.
1. Load the paper .
• Loading Rolls on the Roll Holder (→P .1 15)
• Loading Rolls in the Roll Feed Unit (→P .1 17)
• Loading Rolls in the Printer (→P .1 18)
• Loading Sheets Manually (→P .148)
Note
• Always make sure the loaded paper matches the type of paper specied in the settings. Adjustment
cannot be completed correctly unless the loaded paper matches the settings.
Note that B: Other may not be available when using some types of paper .
2. Press the Menu button to display MAIN MENU .
3. Press ▲ or ▼ to select Adjust Printer , and then press the ► button.
4. Press ▲ or ▼ to select Adjust Length , and then press the ► button.
5. Press ▲ or ▼ to select A: Standard or B: Other , and then press the ► button.
Adjustments for Better Print Quality 583
