Printer Specications
Printer Specications
Specications
Important
• This information is subject to change as the printer is updated.
• The following values may vary depending on the operating environment.
Printer
Power supply 100-120 V AC (50/60 Hz), 220-240 V AC (50/60 Hz)
In operation 100 W max.
Sleep mode 100-120 V : 5 W max.
220-240 V : 6 W max.
Power consumption
Of f 1 W max. ( *1 )
Operating noise Approx. 49 dB (A) max.
T emperature 15-30°C (59-86°F)Operating
environment
Humidity 10-80%, non-condensing
Printer only 1,177×670×344 mm (46.3 × 26.4 × 13.5 in)Dimensions (W × D
× H)
With stand 1,177×870×991 mm (46.3 × 34.3× 39.0 in)
Printer only Approx. 51 kg (1 12.4 lb) ( *2 )W eight
(not including the
Printhead and Ink
T ank )
With stand Approx. 66 kg (145.5 lb) ( *2 )
Printer only 1,477×1,770×644 mm (58.1 × 80.7 × 25.4 in)Space required for
installation ( *3 )
With stand 1,477×1,970×1,291 mm (58.1 × 80.7 × 50.8 in)
Applicable standards International Energy Star Program, Law on Promoting Green
Purchasing, GPN, RoHS, The Eco Declaration, WEEE, U.S.
presidential directives
*1: The printer uses a trace amount of power even when turned of f. T o stop all power consumption,
turn of f the printer and unplug the power cord.
*2: W eight does not include consumables.
*3: Normally , you will need to ensure an unobstructed space of 800 mm (31.5 in) in front of the printer , 300
mm (1 1.8 in) behind, 150 mm (5.9 in) on both sides, and 300 mm (1 1.8 in) above the printer . Only
when printing from the Front Paper Feed Slot , leave 1,300 mm (51.2 in) of unobstructed space in front
of the printer and 700 mm (27.6 in) behind it.
Printing performance
Print method Bubblejet
Maximum resolution 2400 dpi horizontally ( *1 ) × 1200 dpi vertically
Printhead PF-03
Number of nozzles 2,560 per color
*1: Prints with a minimum 1/2400 inch dot pitch between ink droplets.
Printer Parts 79
