Before Use
Part Names
Projector (WUX450/WX520)
■ Front Side
■ Rear Side
■ Bottom Side
Terminals and
connectors (P44)
Projection lens (P45)
Power cord connector
(P143)
Side control
(P42)
Air intake vent
Air filter (P199)
• Do not block the air intake.
Doing so may cause a malfunction.
• Before projection, always remove the
cap. Leaving the cap on may damage
the projector.
Hole caps (P131)
Attach option feet (sold
separately). For instructions
on removing the hole caps,
refer to “Attaching Option
Feet (RS-FT01, Sold
Separately)”.
Infrared remote receiver (P35)
Exhaust vent
Infrared remote receiver (P35)
Lamp cover
Lens shift
side control
(P45)
Anti-theft lock hole
An anti-theft wire cable (not included) can be connected.
Do not block the air exhaust.
Doing so may cause a
malfunction.
Adjustable feet (P130)
