ComAp InteliCompact NT Reference Guide

InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
120
ECU Boost pressure
EBP
ECU Percent load at current speed
EPL
ECU Fuel Level
EFL
ECU Fault Code
FC
Failure Mode Identifier
FMI
SPtM specific values
SPTM VALUES
NAME
ABBREVIATION
DESCRIPTION
Mains Frequency
Mfrq
Mains frequency
Mains Voltage
Vm1
Mains voltage Ph1
Mains Voltage
Vm2
Mains voltage Ph2
Mains Voltage
Vm3
Mains voltage Ph3
Mains Active Power
Pmns
Mains active power
Mains Reactive Power
Qmns
Mains reactive power
Mains Power Factor
MPF
Mains power factor
Mains Load Character
MLCh
Mains load character
Mains Vector Shift
MVS
Mains vector shift
MINT specific values
Information about gen-sets with GCB closed and their overall P and Q. Values can be also found in
LiteEdit Values / Pwr Management and Info (LE ver. 4.4 and higher).
MINT VALUES
NAME
ABBREVIATION
DESCRIPTION
Bus Frequency
Bfrq
Bus frequency
Bus Voltage
Vb1
Bus voltage Ph1
Bus Voltage
Vb2
Bus voltage Ph2
Bus Voltage
Vb3
Bus voltage Ph3
ActualReserve
Ares
Actual reserve
GensLoaded16
GL16
Each bit if set represents gent-set with its GCB
closed
GensLoaded32
GL32
Each bit if set represents gent-set with its GCB
closed
Running ActPwr
TRPA
Overall power from gen-set with its GCB closed
Running Q-Pwr
TRQA
Overall reactive power from gen-set with its GCB
closed
Running Nominal Power
TRPN
Total running nominal power
