User's Manual
153
Figure 5-62 Snapshot
Step 2 Configure parameters.
Table 5-20 Snapshot parameters
Parameter Description
Manual Snapshot Select the number of snapshots that you want to take each time.
Channel Select the channel that you want to configure the settings for.
Type
●
Scheduled
: The snapshot is taken during the scheduled period.
●
Event
: The snapshot is taken for motion detection, video loss, local
alarms and other events.
Size
The size is determined by the resolution of the main stream or sub
stream of the channel.
Quality
Configure the image quality. The higher the level is, the better the image
will become. Level 6 represents the best quality.
Interval Select or customize how frequently snapshots are to be taken.
Step 3 Click
Apply
.
5.7.7 Modifying Channel Name
You can customize channel name.
Step 1 Select
Main Menu
>
CAMERA
>
Camera Name
.
