User's Manual
67
Figure 3-6 Put back the cover
3.3.2 NVR41HS-4KS2/NVR41HS-P-4KS2/NVR41HS-8P-
4KS2/NVR41HS-4KS2/L/NVR41HS-P-4KS2/L/NVR41HS-8P-
4KS2/L/NVR21HS-4KS2/NVR21HS-P-4KS2/NVR21HS-8P-
4KS2/NVR21HS-W-4KS2/NVR11HS-S3H/NVR11HS-P-S3H/NVR11HS-
8P-S3H/NVR21HS-I/NVR21HS-I2/NVR21HS-P-I/NVR21HS-P-
I2/NVR21HS-8P-I/NVR21HS-8P-I2/NVR21HS-S3/NVR21HS-P-
S3/NVR21HS-8P-S3/NVR11HS-W-S2-CE/NVR11HS-W-S2-FCC Series
Procedure
Step 1 Loosen the screws of the upper cover and side panel.
Figure 3-7 Loosen screws
Step 2 Remove the cover in the direction of the arrow as shown in the figure below.
