User's Manual
54
2.2.27 NVR608-4KS2/NVR608H-XI/NVR608RH-XI Series
The NVR608-32-4KS2 series rear panel is shown as below.
Figure 2-74 Rear panel (1)
The NVR608-64-4KS2/NVR608-128-4KS2/NVR608H-32-XI/NVR608H-64-XI/NVR608H-128-XI series rear
panel is shown as below.
Figure 2-75 Rear panel (2)
Figure 2-76 Rear panel (3)
The NVR608RH-32-XI/NVR608RH-64-XI/NVR608RH-128-XI front panel is shown as below.
