User's Manual
310
initiator and the storage target over TCP/IP networks. After the network disk is mapped to the NVR
device through iSCSI, the data can be stored on the network disk.
This function is available on select models.
Step 1 Select
Main Menu
>
STORAGE
>
iSCSI
.
Figure 5-223 iSCSI
Step 2 Set parameters.
Table 5-68 iSCSI parameters
Parameter Description
Server Address Enter the server address of iSCSI server.
Port Enter the port of iSCSI server, and the default value is 3260.
Storage Path
Click
Storage Path
to select a remote storage path.
Each path represents an iSCSI shared disk and these paths are generated
when created on the server
Username,
Password
Enter the username and password of iSCSI server.
If anonymous login is supported by iSCSI server, you can enable
Anonymous
to log in as an anonymous user.
Step 3 Click
Apply
.
