Table 41 Expansion card installation order (Low Profile + Low Profile configuration) (continued)
Card priority Card type Slot priority Maximum
allowed
3 40 Gb NICs 2, 1 2
4 10 Gb NICs 2, 1 2
5 FC8 HBA 2, 1 2
6 1 Gb NICs 2, 1 2
7 12 GB SAS HBA 2, 1 2
HBA330 Integrated Slot 1
This table describes about the Expansion card installation order (Full Height +Low Profile
configuration)
Table 42 Expansion card installation order (Full Height +Low Profile configuration)
Card priority Card type Slot priority Maximum
allowed
1 RAID Integrated Storage Integrated Slot 1
RAID External Storage Low
Profile
2 1
RAID External Storage Full
Height
1 1
2 Infiniband Single Port/Dual
Port (Mellanox)
2 1
3 40 Gb NICs (Low profile) 2 1
40 Gb NICs (Full height) 1 1
4 10 Gb NICs (Low profile) 2 1
10 Gb NICs (Full height) 1 1
5 FC8 HBA (Low profile) 2 1
FC8 HBA (Full height) 1 1
6 1 Gb NICs (Low profile) 2 1
1 Gb NICs (Full height) 1 1
7 12 GB-SAS-HBA (Low profile) 2 1
12 GB-SAS-HBA (Full height) 1 1
8 Non-RAID HBA330 Integrated Slot 1
Removing the expansion card riser
Before you begin
CAUTION
Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
Installing and removing system components
128 Dell PowerEdge R430 Owner's Manual
