5. Enter the correct time and date in the System Setup Time and Date fields.
6. Exit System Setup.
Hard-drive backplane
Depending on your system configuration:
PowerEdge R430 supports
Four 3.5 inch or 2.5 inch SAS/SATA backplane or
Eight 2.5 inch SAS/SATA backplane or
Ten 2.5 inch SAS/SATA backplane
Removing the hard drive backplane
Before you begin
CAUTION Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
directed by the online or telephone service and support team. Damage due to servicing that is
not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that are shipped with your product.
CAUTION To prevent damage to the drives and backplane, you must remove the hard drives
from the system before removing the backplane.
CAUTION You must note the number of each hard drive and temporarily label them before
removal so that you can replace them in the same locations.
1. Follow the safety guidelines listed in the Safety instructions section.
2. Follow the procedure listed in the Before working inside your system section.
3. Remove all hard drives.
Procedure
1. Disconnect the SAS/SATA data, signal, and power cable(s) from the backplane.
2. Press the release tabs and lift the backplane upward and slide it toward the back of the
chassis.
Installing and removing system components
162 Dell PowerEdge R430 Owner's Manual
