Processor specifications
The PowerEdge R430 system supports up to two Intel Xeon E5-2600 v3 or Intel Xeon E5-2600 v4
product family processors.
PSU specifications
The PowerEdge R430 system supports up to two AC redundant power supply units (PSUs) and a
single AC cabled PSU.
For 550 W AC, platinum power supply unit, the maximum heat dissipation is 2107 BTU/hr,
frequency is 50/60 Hz, and voltage range is 100240 V AC autoranging and the current rating is
between 7.4 A-3.7 A. For 450 W AC Bronze PSU, the maximum heat dissipation is 1871 BTU/hr,
frequency is 50/60 Hz, and voltage range is 100240 V AC autoranging and the current rating is
between 605 A-3.5 A.
Table 20 PSU specifications
PSU Class Heat
dissipation
(maximum)
Frequ
ency
Voltage Current
550 W AC Platinu
m
2107 BTU/hr 50/60
Hz
100–240 V AC,
autoranging
7.4 A-3.7 A
450 W AC Bronze 1871 BTU/hr 50/60
Hz
100–240 V AC,
autoranging
6.5 A-3.5 A
Note: Heat dissipation is calculated using the PSU wattage rating.
Note: This system is also designed to connect to the IT power systems with a phase-to-phase
voltage not exceeding 230 V.
System battery specifications
The PowerEdge R430 system supports 3 V CR2032 Lithium coin cell system battery.
Expansion bus specifications
The PowerEdge R430 system supports PCI express (PCIe) Generation 2 and 3 expansion cards,
which need to be installed on the system board using expansion card risers. This system supports
two types of expansion card risers. The following table provides the expansion card riser
specifications:
This table describes the details of the PICe slots on the expansion card risers. PCIE_G3_X16 riser
supports PCIe slots 1 and 2 with low-profile, half-length, x16 link speed cards. PCIE_G3_X8 riser
supports two PCIe cards on slots 1 and 2 with a full height, low profile, x8 link speed cards on slot 1
and a low-profile, half-length, x8 link speed card on slot 2
Technical specifications
Dell PowerEdge R430 Owner's Manual 43
