Recommended tools
You need the following tools to perform the removal and installation procedures:
l
Key to the bezel lock.
This is needed only if your system includes a bezel.
l
Phillips #1 screwdriver
l
Phillips #2 screwdriver
l
Plastic scribe
l
Wrist grounding strap
Front bezel (optional)
The front bezel is attached to the front side of the server and prevents accidents while removing
the hard drive or when pressing the reset or power button. The front bezel can also be locked for
additional security.
Removing the optional front bezel
Before you begin
Follow the safety guidelines listed in the Safety instructions section.
Procedure
1. Locate and remove the bezel key.
Note:
The bezel key is attached to the back of the bezel.
2. Unlock the bezel by using the key.
3. Slide the release latch up and pull the left end of the bezel.
4. Unhook the right end, and remove the bezel.
Figure 17
Removing the optional front bezel
Installing and removing system components
Dell PowerEdge R430 Owner's Manual 85
