Dell E28S Series User Manual

Figure 101 Removing the system board
a. screw (9)
b. system board
c. system board t-handle
Installing the system board
Before you begin
CAUTION
Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
directed by the online or telephone service and support team. Damage due to servicing that is
not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that are shipped with your product.
CAUTION Do not lift the system board by holding a memory module, processor, or other
components.
CAUTION Take care not to damage the system identification button while placing the system
board into the chassis.
Installing and removing system components
Dell PowerEdge R430 Owner's Manual 185
