Dell SonicWALL Secure Mobile Access 8.5
Administration Guide
109
Configuring SNMP Settings
To configure the SNMP Settings fields:
1 Navigate to System > Administration.
2Select Enable SNMP.
3 Type the name (FQDN) of the system into the System Name field.
4 Type the email address of the system contact into the System Contact field.
5 Type the city or other identifying location of the system into the System Location field.
6 Type the asset number of the system into the Asset field. The asset number is defined by the
administrator.
7 Type the public community name into the Get Community Name field. This name is used in SNMP GET
requests.
8Click Accept to save your changes.
Enabling GMS Management
The Dell SonicWALL Global Management System (GMS) is a web-based application that can configure and
manage thousands of Dell SonicWALL Internet Security appliances, including global administration of multiple
site-to-site VPNs from a central location.
Complete the following steps to enable GMS management of your SMA/SRA appliance:
1 Navigate to System > Administration.
2Select Enable GMS Management.
3 Type the host name or IP address of your GMS server in the GMS Host Name or IP Address field.
4 Type the port number of your GMS server in the GMS Syslog Server Port field. The default for
communication with a GMS server is port 514.
5 Type the desired interval for sending heartbeats to the GMS server in the Heartbeat Interval (seconds)
field. The maximum heartbeat interval is 86400 seconds (24 hours).
6Click Accept to save your changes.
External FTP/TFTP Server
The External FTP/TFTP Server section allows you to configure an external FTP server to backup your settings
and diagnostic data.
