Dell SonicWALL Secure Mobile Access 8.5
Administration Guide
444
Linksys WRT54GS
The SMA/SRA appliance should be configured on the LAN switch of the Linksys wireless router. This guide
assumes that your Linksys is assigned a single WAN IP, through DHCP by the cable ISP and is using the default LAN
IP address scheme of 192.168.1.0/24.
To configure your Linksys for operation with the SMA/SRA appliance, you must forward the SSL (443) port to the
IP address of the SMA/SRA appliance.
1 Log in to the Linksys device.
2 Navigate to the Applications & Gaming tab.
3 Enter the following information:
4 With the configuration complete, click Save Settings on the bottom of the page.
The Linksys is now ready for operations with the SMA/SRA appliance.
WatchGuard Firebox X Edge
This guide assumes that your WatchGuard Firebox X Gateway is configured with an IP of 192.168.100.1 and your
SMA/SRA appliance is configured with an IP of 192.168.100.2.
Before you get started, take note of which port the WatchGuard is using for management. If the WatchGuard is
not being managed on HTTPS (443), perform the following steps. If the WatchGuard is being managed on HTTPS
(443) you’ll need to first review the notes within this guide.
NOTE: Version 2.07.1 Firmware or newer is recommended for this setup.
Table 47. Information to be added to Applications & Gaming tab
Application SMA/SRA The name for the port forwarded application.
Port Range Start 443 The starting port number used by the
application.
Port Range End 443 The ending port number used by the
application.
Protocol TCP The SMA/SRA application uses TCP.
IP Address 192.168.1.10 The IP address assigned to the SMA/SRA
appliance.
Enable Checked Select the check box to enable the SSL port
forwarding.
NOTE: The steps that follow are similar for WatchGuard SOHO6 series firewall.
