The shelf must have at least two fan modules installed while the shelf is powered up;
do not remove more than one fan module while AC power is on. There is a five minute
limit to replace a fan before the system may start shutting down the disk drives. Do
not remove a faulted fan unless a replacement is on hand and available to be installed
within five minutes.
Procedure
1. Refer to the previous figure to perform this procedure. Unlock the fan module
by pushing the orange tab to the left.
2. Pull up on the latch handle to release the fan module.
3. Pull the fan module up and out of the chassis.
Installing a fan
Before you begin
The shelf must have at least two fan modules installed while the shelf is powered up;
do not remove more than one fan module while AC power is on. There is a five minute
limit to replace a fan before the system may start shutting down the disk drives. Do
not remove a faulted fan unless a replacement is on hand and available to be installed
within five minutes.
Attach an ESD wristband to your wrist and the shelf where you will install the fan.
Removing and Replacing FRUs
Installing a fan 97
