Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
PRODUCT DESCRIPTION Basic Specifications 14
SE Group Confidential (Related Staff Only)
1.2 Basic Specifications
1.2.1 Basic Specifications
Note *1: Use a shielded twisted pair cable (category 5 or higher).
"*2": Nozzle set configuration are;
1.2.2 Electric Specifications
Table 1-3. Basic specifications
Item Specification
Print method On-demand inkjet
Print Head
Number of nozzles 360 nozzles x 2 lines x 4 (colors)
Configuration of nozzles 720 nozzles for each color*
2
Line width of nozzles 1 inch
Maximum resolution 720 x 1440 dpi
Control code ESC/P Raster
Paper feed method Friction
RAM
For Main 512 MB
For Network 128 MB
Interface
 USB 2.0 HS
 Ethernet (100Base-T/1000Base-T)*
1
Temperature
Operating
15 °C to 35 °C
(recommended: 15 to 25 °C)
Storage (before unpacking)
-20 °C to 60 °C
(no more than 120 hours at 60 °C,
within a month at 40 °C)
Storage (after unpacking)
-20 °C to 40 °C
(within a month at 40 ℃ )
Humidity
Operating
20% to 80% (recommended: 40 to 60%)
(Non condensing)
When storing (packed/unpacked) 5% to 85% (Non condensing)
Table 1-4. Nozzle Layout (Head 1)
A B C D E F G H I J
--- --- C Y M K K M Y C
Table 1-5. Nozzle Layout (Head 2)
A B C D E F G H I J
--- --- C Y M K K M Y C
Table 1-6. Electric specifications
Item
Specification
Printer Heater
Rated voltage AC100 to 240V AC200 to 240V
AC100-120V
AC200-240V
Input voltage range AC90-132V AC180-264V ---
Rated frequency 50 to 60Hz 50 to 60Hz
Rated current
1) 12A
2) 12A
1) 6A
2) 6A
1) 1A
2) 0.5A
Power
consumption
Printing
1) Approx. 110W
2) Approx. 650W
Approx. 45 W
Ready mode
1) Approx. 38W
2) Approx. 420W
---
Sleep mode
1) Approx. 11W
2) Approx. 0.1W
Approx. 0.3 W
Power off
1) Approx. 0.9W
2) Approx. 0.1W
Approx. 0.3 W or less
Power
consumption
(Total for
numbers 1 and
2)
Printing Approx. 760W
Ready mode Approx. 458W
Sleep mode Approx. 11W
Power off Approx. 1W
