4.8 References
This function allows you to view the following information (PDF files).
 Control panel menus in the Normal Mode
 Control panel menus in the Serviceman Mode
 Wiring diagrams
PROCEDURE
1. Click [References] from the main menu.
2. Select Panel Menu Map or Wiring Diagrams and click [Open].
Figure 4-12. References
