Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
PRODUCT DESCRIPTION Hardware Specifications 17
SE Group Confidential (Related Staff Only)
1.4 Hardware Specifications
This section provides the printer dimensions and shows the main components.
1.4.1 Dimensions and Weight
DIMENSIONS
Figure 1-3. Dimensions
WEIGHT
1.4.2 Installation Room Requirement
Figure 1-4. Installation Room Requirement
Table 1-9. Dimensions
Description Width Depth Height
Stored 2,620 mm 1,013 mm 1,314 mm
Maximum 2,620 mm 1,198 mm 1,653 mm
Depth
Height
Width
Table 1-10. Weight
Item Weight
Main body 155.5 kg
Standard Roll Unit 34.3 kg
Standard Reel Unit 42.8 kg
Legs 40.4 kg
Drying Fan Unit 9.0 kg
Ink tank 6.0 kg
Ink tank unit 8.6 kg
Total weight 296.6 kg
