SC-F9200 Series Revision C
APPENDIX Connection Diagram 397
SE Group Confidential (Related Staff Only)
6.2.6 CR drive mechanism
SUB-D Board
Main Board
1
2
4
3
7
Main-B Board
PSH Board
5
6
PSH-B Board
