SC-F9200 Series Revision B
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 244
SE Group Confidential (Related Staff Only)
3.4.9 Reel Unit
3.4.9.1 Media Guide Bar
1. Remove the four screws, and remove the Media Guide Bar.
A) Special screw: 4 pcs
Figure 3-199. Removing the Media Guide Bar
A
A
Left side
A
Media Guide Bar
