Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
APPENDIX Part names used in this manual 409
SE Group Confidential (Related Staff Only)
6.3 Part names used in this manual
To make it easier to locate the target part from its part name, this manual uses the part
names different from the ASP part names. The table below shows the conversion of the
part names used in this manual and the corresponding ASP part names.
Table 6-1. Conversion Table
Part name used in this manual ASP part name
Ref.
(Ch3 sec.No.)
Housing
Panel Unit PANEL ASSY ESL;ASP 3.4.3.1
Right Upper Cover
 COVER,TOP,RIGHT,ASSY;
ASP
 COVER,MAINTENANCE
 COVER,MAINTENANCE,R
IGHT,ASSY;ST ASP
3.4.3.2
Lower Ink Holder N/A 3.4.3.3
Right Front Cover
 COVER,FRONT,RIGHT,64,
ASSY;ST ASP
 COVER,IH
3.4.3.4
Right Cover
COVER SIDE RIGHT DOWN
ASSY ESL;ASP
3.4.3.5
Right Lower Cover
HOUSING,BASE,SUPPORT,
RIGHT
3.4.3.6
Left Rear Cover CAP,COVER,TUBE 3.4.3.7
Left Upper Cover
 COVER,TOP,LEFT,ASSY;
ASP
 COVER,MAINTENANCE,
HEAD
 COVER,MAINTENANCE,L
EFT, ASSY.;ST ASP
3.4.3.8
Left Front Cover
COVER FRONT LEFT
ASSY.;ST ASP
3.4.3.9
L Maintenance Cover Sensor
FULL,MAINTENANCE
OPEN ASSY ESL;ASP
3.4.3.9
Left Cover
COVER SIDE LEFT DOWN
ASSY ESL;ASP
3.4.3.10
Left Lower Cover
HOUSING,BASE,SUPPORT,L
EFT
3.4.3.11
Upper Cover N/A 3.4.3.12
Board Box Cover N/A 3.4.3.13
Housing
R Maintenance Cover Sensor
INK LOCK,MAINTENANCE,
HOME,ASSY ESL;ASP
3.4.3.14
Front Cover R Sensor
INK LOCK,P COVER,
HOME,ASSY ESL;ASP
3.4.3.15
Front Cover L Sensor
PRINTER,COVER,OPEN
ASSY ESL;ASP
3.4.3.16
Electric Circuit
Components
Main Board BOARD ASSY.,MAIN 3.4.4.1
Main-B Board BOARD ASSY.,MAIN 3.4.4.2
PSH Board
BOARD ASSY.,POWER
SUPPLY
3.4.4.3
PSH-B Board
BOARD ASSY.,POWER
SUPPLY
3.4.4.3
Sub Board BOARD ASSY.,SUB 3.4.4.4
Sub-D Board
BOARD ASSY.,SUB,CB78
SUB-D(6644A)
3.4.4.5
Sub-E Board
BOARD ASSY.,SUB,CB78
SUB-E(6645C)
3.4.4.6
Sub-M Board
BOARD ASSY.,SUB,CB81
SUB-M(6626B)
3.4.4.7
Box Cooling Fan FAN SET.DC;ASP 3.4.4.8
Power Supply Board Cooling
Fan
FAN SET. DC(PROPELLER
TYPE)
3.4.4.9
Carriage Mechanism/
Ink System
Mechanism
CR Cover COVER,CR 3.4.5.1
Duct CR
DUCT CR ASSY;CE30
ESL;ASP
3.4.5.2
Print Head PRINT HEAD,IE343J 3.4.5.3
Table 6-1. Conversion Table
Part name used in this manual ASP part name
Ref.
(Ch3 sec.No.)
