Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
ADJUSTMENT Other Printer Checks and Adjustments 358
SE Group Confidential (Related Staff Only)
4.15.8 Rear AD Adjustment
REQUIRED TOOL
 Standard Sheet (JETRAS JP-D300S)
EXECUTION MODE
Serviceman Mode
PROCEDURE
1. When any paper is loaded, remove it.
2. Check the all Ink Cartridge Lock Lever are lower position.
3. Turn the printer ON in the Serviceman Mode.
Turn the power ON while pressing [Menu] + [Back] + [OK].
4. Select Mecha Adjustment → Rear AD.
5. Press [OK] while [Enter] Start is displayed.
Check if “Retry AD Adjust” is displayed on the Control Panel.
6. Open the Front Cover.
7. Move the Media Loading Lever to the rear side, and set it to the release position.
8. Insert the Standard Sheet to the position shown in Figure 4-81 and lower the
Media Loading Lever to press the sheet. Make sure to secure the followings.
 Load the sheet with its matte side upper ..... i
 Set the right side of the Standard Sheet between the 12th and 13th hollows on
the Adjustment Plates from the right.
 Set the Standard Sheet while aligning the long side with the front end of the
Platen.
9. Press [OK].
Check that a number is displayed on the Control Panel and record it. If Retry AD
Adjust is displayed, check if there is a defect (tears/rips, contamination, wrinkles)
on the Standard Sheet, and retry this step.
10. Turn over the sheet, (Load the sheet with its matte side under)..... ii
Again, press [OK].
Check that a number is displayed on the Control Panel and record it. If Retry AD
Adjust is displayed, check if there is a defect (tears/rips, contamination, wrinkles)
on the Standard Sheet, and retry this step.
11. Compare i with ii, check fulfilling the following condition.
Standard: 75~127 and i < ii
12. Remove the Standard Sheet, and turn the printer OFF.
C H E C K
P O I N T
Make sure to carry out the following steps without loading the
Standard Sheet.
C H E C K
P O I N T
If “0” is displayed, check if Ink Cartridge Lock Lever is top
position.
C A U T I O N
When executing the following step, do not remove the external
covers to acquire proper AD value.
C A U T I O N
If Retry AD Adjust is displayed again, the PE sensor is defective.
Replace the PE sensor with a new one and carry out the adjustment
again.
C A U T I O N
If out of standard, check the matte side of standard sheet, and retry
this step.
If out of standard again, replace the PE sensor with a new one.
