9.1 [MEMORY] Screen
135
89
Chapter 9 Data Saving and File Operations
(SYSTEM-MEMORY screen)
9
The PW3198 saves settings data, measurement data, waveform data, event data, and screen copy
data to an optional SD memory card. (Of this data, only setting conditions can be loaded by the
instrument.)
See:"3.5 Inserting (Removing) an SD Memory Card" (p.32)
This section describes the [MEMORY] screen.
Data Saving and File Operations
(SYSTEM-MEMORY
screen) Chapter 9
9.1 [MEMORY] Screen
Displays the current display position. This screen indi-
cates that the contents of the PW3198 folder on the SD
memory card are being displayed.
Displays a list of files saved on the SD
memory card.
Allows you to scroll around the
screen with the up and down cur-
sor keys and displays the current
display position as a white bar.
Displays how much of the SD memory
card has been used.
An error message will be displayed if the SD memory card experiences an error. SD utili-
zation is not shown.
To Next Page
