13.7 Configuration Function Specifications
194
13.7 Configuration Function Specifications
Detailed description of Urms type, PF type, THD type, and harmonics
Urms type PF type THD type Harmonics
Measured value
(DMM screen)
Selection is applied to RMS voltage (Urms) only
and does not affect RMS voltage refreshed
each half-cycle or transient measured values.
Selection is
applied.
Selection is
applied.
Selection is applied.
Measured value display
switching
(DMM screen display only)
Phase voltage/line voltage switched on
DMM screen.
- -
Level/content
percentage switched
on DMM screen.
TIMEPOT and events Selection on main settings screen is applied
to RMS voltage (Urms) but does not affect
RMS voltage refreshed each half-cycle or
transient events.
Selection on
main settings
screen is applied.
Selection on main
settings screen is
applied.
Selection on main
settings screen is
applied.
Binary data storage
(displayed on computer ap-
plication)
Phase voltage and line voltage
Power factor and
displacement
power factor
THD-F and
THD-R
Level and content
percentage
Other
Valid with 3P3W3M, 3P4W, and 3P4W2.5E
connections. Does not apply to waveform.
DPF values for
channels (ex-
cluding sum val-
ues) for 3P3W2M
and 3P3W3M
connections are
undefined.
Power (small) / P&Harm (normal) / all data (full) details
Recorded item Power P&Harm All Data Recorded item Power P&Harm All Data
RMS voltage refreshed
each half-cycle
Yes Yes Yes Harmonic voltage Yes Yes
RMS current refreshed
each half-cycle
Yes Yes Yes Harmonic current Yes Yes
Frequency Yes Yes Yes Harmonic power Yes Yes
Frequency cycle Yes Yes Yes Harmonic voltage and
current phase difference
Yes Yes
10-sec frequency Yes Yes Yes Harmonic voltage phase
angle
Yes Yes
RMS voltage Yes Yes Yes Harmonic current phase
angle
Yes Yes
RMS current Yes Yes Yes
Voltage waveform peak Yes Yes Yes Inter-harmonic voltage Yes
Current waveform peak Yes Yes Yes Inter-harmonic current Yes
Active power Yes Yes Yes Total harmonic voltage
distortion factor
Yes Yes Yes
Apparent power Yes Yes Yes Total harmonic current
distortion factor
Yes Yes Yes
Reactive power Yes Yes Yes
Power factor/displace-
ment power factor
Yes Yes Yes High-order harmonic
voltage component
Yes Yes Yes
Voltage unbalance factor Yes Yes Yes High-order harmonic
current component
Yes Yes Yes
Current unbalance factor Yes Yes Yes K factor Yes Yes Yes
Instantaneous flicker
value
Yes Yes Yes
Integral power Yes Yes Yes Flicker (V10/Pst, Plt) Yes Yes Yes
