[VIEW] screen
Mode Display Display
updates
Displayed screens
[SETTING]
[RECORDING]
Real-time data Approx.
0.5 s
Waveform display, vector display, DMM display, harmonic bar graph
display, harmonic list display
[ANALYZING] Event data selected on
[TIMEPLOT] or [EVENT] screen
Waveform display, transient overvoltage waveform display, DC wave-
form display, vector display, DMM display, harmonic bar graph dis-
play, harmonic list display, high-order harmonics
Waveform display
Displayed screens 1. Voltage/ Current : 2-segment split display (voltage waveform (U1 to U4) Current waveform (I1
to I4))
2. Voltage 4 channels: 4-segment split display (voltage waveform (U1 to U4))
3. Current 4 channels: 4-segment split display (current waveform (I1 to I4))
Harmonic display
Displayed screens Vector/harmonic graph/harmonic list
The screen displays 10-/12-cycle RMS values based on the IEC61000-4-30 standard for the RMS
voltage, RMS current, and power for each order on the vector, graph, and list screens.
DMM display
Displayed screens 1. Power, 2. Voltage, 3. Current
The screen shows 10-/12-cycle RMS values based on the IEC61000-4-30 standard for RMS volt-
age and RMS current on the DMM screen.
Transient overvoltage waveform display
Display conditions When an event is selected (event is selected on the waveform display screen)
Display selection All voltage channels
Display period 2 ms before and 2 ms after trigger point
High-order harmonics display
Display conditions When an event is selected (event is selected on the waveform display screen)
Display format High-order harmonic voltage component and current component waveforms
Display selection Channel: Select from CH1, CH2, CH3, and CH4
Display period 40 ms starting after the first approx. 200 ms aggregation interval in which event occurred (8,000
data points)
