5.7 Factory Settings
74
All settings’ default values are as follows:
5.7 Factory Settings
Measurement settings
Setting Default value Setting Default value
WIRING
CH123: 3P4W
CH4: ACDC
ClampSensor
CH123: 9661
CH4: 9661
Phase Name RST I Range
CH123: 500 A
CH4: 500 A
PT Ratio
CH123: 1
CH4: 1
CT Ratio
CH123: 1
CH4: 1
Udin 230 V THD Type THD-F
Frequency 50 Hz Harm Calc U,I,P: All Levels
URMS Type PHASE-N Flicker
Varies with set display
language.
PF Type PF
Measurement period and recording settings
Setting Default value Setting Default value
Time Start OFF TIME PLOT Interval 1 min
Repeat Record OFF Disp COPY Interval OFF
Recording Items ALL DATA
Hardware settings
Setting Default value Setting Default value
Language Set language LCD Backlight ON
Color COLOR1 External Out ShortPulse
Beep ON RS-232C OFF
Vector area settings
Setting Default value Setting Default value
Phase ±30 U/I Angle 0
Level ±20
