ENGINE

- 129 -

ENGINE REMOVAL

No. Part Name Qty Remarks

Removing Throttle and intake

manifold.

Remove the parts in the order listed.

Water temperature sensor

O-ring

Fuel injection

Washer φ6×2

Seat fuel injection

Bolt M6×20

Ducting dampers

Inlet Temperature/pressure sensor

Bolt M4×8

Pressure plate tmap

Clip 50-70

Inlet joint head

For installation, reverse the removal

procedure.
