SPECIFICATIONS
- 72 -
ELECTRICAL SPECIFICATIONS
Item Standard Limit
Voltage 12 V ----
Ignition system
Ignition timing (BTDC)
Advancer type
12°/ 1,500 r/min
ECU Digital type
----
----
Ignition coil
Minimum spark gap
Primary winding resistance
Secondary winding resistance
6 mm (0.24 in)
0.18 ~ 0.28 Ωat 20 °C (68 °F)
6.32 ~ 9.48 kΩat 20 °C (68 °F)
----
----
----
Spark plug cap
Resistance
5.0~5.5 kΩ
----
High voltage cap
Resistance
4.5~5.0 kΩ
Oxygen sensor
type
25325359
Charging system
Nominal output
Charging coil resistance/color
14 V 23 A at 5,000 r/min
0.32 ~ 0.43Ωat 20 ℃ (68 °F)/White – White
----
----
Rectifier/regulator
Regulator type
No load regulated voltage (DC)
Capacity
Withstand voltage
Semi conductor-short circuit
14.1 ~ 14.9 V
18 A
200 V
----
----
----
----
Battery
Specific gravity
1.32
----
Circuit breaker
Type
Main fuse
Lighting system fuse
Ignition fuse
Auxiliary DC jack fuse
Four-wheel drive fuse
Signaling system fuse
Fuse
30A×1
15 A×1
10 A×1
10 A×1
3 A×1
10 A×1
----
----
----
----
----
----
----
Radiator fan
Running rpm
2,950 r/min
