CHASSIS

- 237-

WHEEL AND TYRE PARTS

FRONT WHEELS

No. Part Name

Qty Remarks

Removing the front wheel

1 Front rim 2

2 Front tyre 2

3 Nut M10 8

Wheel decoration cover Ⅳ

5 Nut M22×1.5 2

1WARNING

：

Securely support the vehicle so

There is no danger of it falling over.

6 Front hub 2

7 cotter pin 3.2×50 2

8 Bolt M10×30 4
